USB-C input, integrated OVP over-voltage protection lithium battery charging product-Module 14/15/18/19

2023-05-12 17:10:00

杨工

Original

248

Summary : 1.1 Name: USB-C input, integrated OVP over-voltage protection lithium battery charging product1.2 Application: Convenient charging equipment, etc.1.3 Battery Pack: 3.7V/3.8V lithium battery pack, multi-cell or single-cell series, optional full chargeof 4.35V (Board 12)/4.2V (Board 13)

14,15，18，19号密码是PWCHIP ，WWW.PWCHIP.COM.zip 1 下载
