Lithium battery charging and discharging board with 5V1A charging, integrated with OVP and boost discharge of 5V2.4A-Module 95
Lithium battery charging and discharging board with 5V1A charging, integrated with OVP and boost discharge of 5V2.4A-Module 95
2023-05-15 11:05:00
UA
Original
282
Summary : 1.1 Name: Lithium battery charging and discharging board with 5V1A charging, integrated withOVP and boost discharge of 5V2.4A1.2 Application: Convenient charging equipment, etc.1.3 Battery pack: 3.7V lithium battery pack, multiple parallel or single series, fully charged at 4.2V,(LED1 is on during charging, LED2 is on when fully charged, LED1 flashes when no battery isconnected)1.4 Input: USB type C port 5V, charging current up to 1000mA1.5 Output: 5V voltage, current up to 2400mA (3.7V lithium battery voltage)
