3S Li-ion battery charging and discharging board with 5V2A input and output through USB-C port-Module 140

2023-05-15 16:32:00

Original

257

Summary : 1.1 Name: 3S Li-ion battery charging and discharging board with 5V2A input and output throughUSB-C port1.2 Application: Convenient charging devices, etc.1.3 Battery pack: 11.1V Li-ion battery pack, 3S multiple parallel configuration, fully charged at 12.6V1.4 Input (USB1): 5V2A (charging LED on, fully charged LED on, flashing LED without battery)1.5 Output (USB1): 5V2.4A (discharging LED on)

140号密码是PWCHIP ，WWW.PWCHIP.COM.zip 1 下载
