PW2609A Input Overvoltage Protection Module with 36V Voltage Endurance, 6.1V and 12V Protection Point-Module 157
PW2609A Input Overvoltage Protection Module with 36V Voltage Endurance, 6.1V and 12V Protection Point-Module 157
2023-05-15 17:57:00
UA
Original
299
Summary : 1.1 Name: PW2609A Input Overvoltage Protection Module with 36V Voltage Endurance, 6.1V and12V Protection Point1.2 Application: USB charging products, power supplies1.3 Input voltage range: 3V-36V, output ≈ input (there is a voltage drop due to internal resistance,and the voltage drop caused by internal resistance increases as the current increases)1.4 Overvoltage setting: When the FB pin is floating, the default overvoltage protection setting is6.1V. To change it to the corresponding overvoltage protection voltage of 12V, both of the solderpads marked with arrows need to be soldered.
