Lithium battery charging and discharging board with 5V1A charging and boost discharging at 5V2.4A-Module 90
Lithium battery charging and discharging board with 5V1A charging and boost discharging at 5V2.4A-Module 90
2023-05-15 10:23:00
UA
Original
275
Summary : 1.1 Name: Lithium battery charging and discharging board with 5V1A charging and boost discharging at 5V2.4A1.2 Application: Convenient charging devices, etc.1.3 Battery pack: 3.7V lithium battery pack, in parallel or series, fully charged at 4.2V(LED1 is on during charging, LED2 is on when fully charged, LED1 flashes when no battery isconnected)1.4 Input: USB Type-C port with 5V, charging current up to 1000mA1.5 Output: 5V voltage, current up to 2400mA (with 3.7V lithium battery voltage)
